Standard frequency vibratory 38M

Standard frequency vibrators

Vibration frequency 1400 to 1700 RPM at high amplitude. These are the vibrators to use when high power is required and the site you are working on is not vibration-sensitive.

Standard frequency vibrators	25M	38M	52M	55M	82M	110M	200M	300M
Eccentric moment	27 kgm	38 kgm	52 kgm	54 kgm	81 kgm	110 kgm	200 kgm	286 kgm
Max frequency	1700 RPM	1700 RPM	1700 RPM	1700 RPM	1700 RPM	1350 RPM	1400 RPM	1400 RPM
Max centrifugal force	856 kn	1200 kn	1650 kn	1711 kn	2567 kn	2198 kn	4300 kn	6150 kn
Max hydraulic power	272kW/370HP	295kW/401HP	435kW/590HP	360kW/489HP	518kW/704HP	558kW/759HP	980Kw/1333HP	1635kW/222HP
Max extraction capacity	400 kn	400 kn	500 kn	800 kn	800 kn	800 /12000kn	1800 kn	4000 kn
Total weight*	4980 kg	5400 kg	6850 kg	5700 kg	7900 kg	12000/13500 kg	30000 kg	44000 kg
Dynamic weight*	2900 kg	3000 kg	4000 kg	3580 kg	5400 kg	7000 kg	21000 kg	27250 kg
Max amplitude*	19 mm	25 mm	26 mm	30 mm	30 mm	31 mm	19 mm	21 mm
L x D x H mm*	2390x661x1976	2430x700x2100	2790x748x2252	2642x678x1939	2662x721x2427	3235x1088x3065	3856x1600x3405	5034x1800x4295
Power plant power	480	500	800	600	900	1000	1600	2800
Sheet pile clamp	110T	150T	200T	200TU	320TU	350T
Tube cap	2x55T	2x80T	2x125T	2x100T	2x175T	2x150T	4x150T	4x200TC
Download PDF file	PVE25M_PAJOT	PVE38M_PAJOT	PVE52M_PAJOT	PVE55M_PAJOT	PVE82M_PAJOT	PVE110M_PAJOT	PVE200M_PAJOT	PVE300M_PAJOT

*without clamp
